<1>Axles
Lub txaj qis semitrailer tuaj yeem siv cov axles sib txawv rau kev sib txawv ceev thiab txoj kev. Rau txoj kev siab, peb yuav muab lub teeb qag, rau txoj kev off-txoj kev, peb muab hnyav axles.
<2>Qhov loj ntawm lub cev thiab cov log tsheb
Cov khoom sib txawv yuav tsum muaj cov khoom thauj sib txawv, peb tsim thiab tsim cov khoom sib txawv loading lawj kom tau raws li qhov xav tau tiag tiag rau peb cov neeg siv khoom. Lub lawj thauj khoom tuaj yeem ua tau txawm tias txuas ntxiv, thiab lub caj dab goose tuaj yeem raug tshem tawm. Peb yuav siv ntau qhov sib txawv ntawm cov log tsheb sib txawv rau cov tsheb thauj khoom sib txawv.
<3>Hydraulic system
Qee cov neeg siv khoom yuav xav tau qhov sib txawv ntawm qhov sib txawv rau lub trailer rau lub tshuab ua haujlwm hnyav, lossis lwm yam khoom siv. Ib txhia nyiam phau ntawv ramp, ib txhia yuav nyiam phau ntawv sawv daws yuav. Peb yuav muab cov lus pom zoo thiab muab cov kev daws teeb meem zoo rau cov neeg siv khoom, kom nyab xeeb tus nqi, lossis muab kev nyab xeeb zoo dua rau lawv cov khoom xa tuaj.
<4>Reflection system
Peb tuaj yeem muab cov teeb pom kev zoo los yog lub teeb pom kev zoo rau kev txhawj xeeb txog kev nyab xeeb.
<5>Lwm tus
Lwm qhov chaw yuav raug ntxiv lossis tshem tawm raws li cov neeg siv khoom xav tau.
Parameter
|
Yam khoom |
Tsawg txaj semi trailer |
|
Tare luj |
7/9/15T |
|
qhov ntev |
11000/13000/16000mm * 2490mm * 1575mm |
|
Chaw thau khoom muaj peev xwm |
60 Tuj ~ 120 Tuj |
|
Qag |
13T/16T/20T/25T, FUWA/BPW/Huajing Brand |
|
Rim |
9.00-22.5 |
|
Lub log |
11.00R20/1200R22.5 |
|
Kev ncua |
Mechanical suspension (Lub teb chaws Yelemees Hom lossis Asmeskas Hom) Los yog Cua ncua kev kawm (Tuam Tshoj hom lossis BPW Hom) |
|
Nplooj nplooj |
90 (w) mm * 13 (thickness) mm * 10 Layer los yog 100mm * 12mm * 12 |
|
King pin |
Jost hom 2.0 0r 3.5 nti bolts hom lossis vuam hom |
|
Txhawb ceg |
JOST hom D200T lossis Tuam Tshoj hom 28Tons (ob zaug ceev) |
|
Main beam |
Qhov siab: 500 hli, raws li phaj yog 18 hli, nruab nrab phaj yog 10 hli, nqes phaj yog 18 hli; Khoom siv yog Q345B Steel |
|
Sab beam |
18 "# channal steel (Cov khoom yog Q235steel) |
|
Nres chamber |
WABCO RE 6 relay valve; T30 / 30+T30 Caij nplooj ntoos hlav nres chamber |
|
ABS |
Xaiv tau |
|
Twist Locks |
Plaub, Yim, kaum ob daim (Lifting type lossis Twist Screw Type) |
|
Valve |
WABCO valve |
|
Teeb |
LED teeb |
|
Qhov hluav taws xob |
24V |
|
Txais |
7 txoj kev (7 hlau hlua) |
|
Tool lub thawv |
Ib thooj, 1m * 0.5m * 0.5m (Qhov Loj tuaj yeem xaiv tau dawb) (nrog 1 unit Tire spanner, 1 unit gudgeon tes tsho thiab 1 unit cranking bar) |
|
Kev pleev xim |
Ua kom tiav Chassis xuab zeb blasting los ntxuav xeb, 1 lub tsho tiv no ntawm anticorrosive prime, 2coats ntawm cov xim kawg |
|
Lub sij hawm shipping |
Thauj los ntawm cov neeg nqa khoom thauj khoom loj, RORO lossis 40HQ thawv |
Ua haujlwm
Lub Sijhawm Ntau Lawm: 35 Hnub
Kev Cai Clearance: 5 Hnub
Daim ntawv ceeb toom:
• 3 khub nkawm khau nres
• 1 lub log tsheb seem
• Cov Khoom Siv Ua Haujlwm Ua Haujlwm
• Cov tshuaj tua hluav taws
Cov khoom saum toj no tau muab pub dawb rau cov tsheb thauj khoom xa tawm mus rau txawv teb chaws, kom lav cov neeg siv khoom thauj khoom zoo.
Lwm tus:
Lub trailer tshiab yuav tau waxed ob zaug ua ntej xa zaub mov, los tiv thaiv nws cov duab los ntawm dej los yog cua los ntawm dej hiav txwv.
